ESD Stereo Zoom Microscope JBM-PL52

ESD Stereo Zoom Microscope JBM-PL52 Specification

Features
ESD Safe construction, Ergonomic design, Crisp & Clear Image, Maintenance Free, Suitable for electronics & PCB Inspection

View Head
Binocular, 360 rotatable

Focus System
Rack and Pinion, Precise Focus

Spare Parts
Replacement eyepieces, objectives, bulbs, stage plates

Theory
Stereo Zoom Microscopes offer a three-dimensional view, high depth of field, and variable magnification, ideal for precise inspection work in ESD-sensitive environments.

Drawtube
Binocular

Sensor
Not Applicable (Optical Microscope)

Resolution
High Resolution Optical System

Focal Distance
100mm

Magnification
7x to 45x (Zoom)

Dimensions
Approx. 340mm x 250mm x 400mm (H x W x D)

Focus Range
55mm

Eyepieces
WF10x/20mm, High Eye Point

Eyepiece Tube
Inclined at 45, rotatable 360

Illumination
Top & Bottom LED (Incident and Transmitted)

Coarse Adjustment Range
No Coarse Adjustment, Precision Focusing

Fine Adjustment Range
Provided (Precise Fine Focus Mechanism)

Working Stage
ESD Safe Frosted Glass & Black/White Plate

Interpupillary Distance
55-75mm adjustable

Objective Achromatic
0.7x to 4.5x Zoom Objective

Condenser
Not Applicable (Stereo Microscope)

Light Source
LED Illumination, both Incident and Transmitted, ESD Safe

Application
PCB Inspection, Jewelry, Biological Research, Education, Industrial Quality Assurance

Power Supply
AC 110/220V, 50-60Hz

Additional Accessories
Dust Cover, ESD Grounding Cord, User Manual

Net Weight
Approx. 6.5 kg

Stand Type
Sturdy, Heavy Duty Metal Stand, ESD Safe Coating

Stage Size
160mm x 180mm

Operating Humidity
85% RH

Color
Matte Black/Gray (Anti-reflective)

Body Material
Aluminium Die-cast with Electrostatic Powder Coating

ESD Stereo Zoom Microscope JBM-PL52 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
3 Days

About ESD Stereo Zoom Microscope JBM-PL52

Magnification range	7x 52x
Magnification	0.65-52X
Zoom ratio	7x
Head type	Trinocular
Brand	JB MICROSCOPE
Illumination type	LED
Working distance	120 mm
Stand type	Table stand
Model Name/Number	JBM-PL52
Eyepiece magnification	10x
Reflected light	Top bottom light
Application	PCB inspection, Jewellery, Industrial, Research
Country of Origin	Made in India

Minimum order quantity: 1 Piece

6.5X-52X LARGE MAGNIFICATION CONTINUOUS MULTIPLICATION AND FILE FIXING FUNCTION Accurately lock the magnification
required for observation, high-definition effect imaging, and freely switch between different magnifications to capture more details.

MODEL-JBM-PL52
Camera Feature: Automatic edge finding built-in measuring system. Local magnification electronic zoom/zoom image mirroring, u disk storage
Magnification:0.65-52X, zoom ratio8:1 to ensure the focal point of the image plane
Optical multiple:6.5-2X (optional auxiliary objective)
Working distance:155MM (upper & lower range adjustable)
eyepiece 10X/24mm (field of view)
Power Supply:DC-12V/1A
Bracket Size:260X320mm Column height240mm&32mm
Photographic Interface:0.5x,C-mount, adjustable focus
Output interfaced: HDMI + USB High- speed dual output
External devices HDMI Monitor Computer

Exceptional Imaging Versatility

The JBM-PL52 delivers high depth of field, sharp resolution, and variable magnification from 7x to 45x. With a 100mm focal distance and WF10x/20mm high eye point eyepieces, users experience comfortable, ergonomic viewing over long sessions. The 360 rotatable, binocular head and adjustable interpupillary distance enable personalized, fatigue-free operation.

Designed for ESD-Sensitive Environments

Built with an aluminium die-cast, ESD safe powder-coated body, the microscope ensures safe handling of static-sensitive electronic components. The ESD-safe stage surfaces and grounding cord protect both users and specimen from harmful electrostatic discharge during delicate inspections.

Enhanced Illumination and Usability

Top and bottom LED lighting give users precise control over illumination, essential for detecting subtle differences on diverse surfaces. The frosted glass and black/white plates cater to varying sample types, while precision fine focus and smooth rack and pinion mechanisms support exact measurements and repeatable results.

FAQ's of ESD Stereo Zoom Microscope JBM-PL52:

Q: How does the ESD safe coating benefit users during PCB inspection?

A: The ESD safe coating on the JBM-PL52 prevents static discharge, protecting sensitive electronic components from damage during inspection, making it highly suitable for electronics and PCB work environments.

Q: What is the magnification range of the JBM-PL52, and how is it adjusted?

A: The microscope features a zoom magnification range from 7x to 45x, adjustable through the precision zoom objective and fine focusing mechanism, allowing users to switch seamlessly between detailed views and broader inspections.

Q: When should I use the included incident and transmitted LED illumination?

A: Use incident (top) LED illumination for opaque samples like circuit boards or jewelry. For transparent or semi-transparent specimens, such as biological samples, employ transmitted (bottom) lighting for clearer observation.

Q: Where is this stereo zoom microscope commonly applied?

A: The JBM-PL52 is widely used in PCB inspection, jewelry analysis, biological research, education, and quality assurance in industrial settings, especially where ESD protection is critical.

Q: What accessories come with the JBM-PL52, and how do they support its operation?

A: The package includes a dust cover, ESD grounding cord, and user manual. The grounding cord ensures ESD safety, the dust cover keeps the microscope clean, and the manual provides step-by-step operation guidance.

Q: How does the ergonomic design of the microscope benefit users during prolonged operation?

A: Ergonomic features, such as the inclined viewing tube, adjustable interpupillary distance, and a 360 rotatable head, promote comfortable posture, reduce eye strain, and enable fatigue-free use even during extended inspection sessions.
