Digital Inspection MicroscopeCamera JBM-PL6

Digital Inspection MicroscopeCamera JBM-PL6 Specification

Focus System
Coarse and fine focusing

Spare Parts
Supplied with power adapter, dust cover, and calibration slides

View Head
Trinocular head

Features
Live image preview, measurement tools, image capture and analysis software

Theory
Other

Drawtube
Trinocular

Sensor
High-resolution CMOS/CCD sensor

Resolution
12 Megapixels

Interface
USB 2.0, HDMI

Frame Rate
30fps (Full HD)

Focal Distance
Adjustable, 10mm - 500mm Millimeter (mm)

Magnification
Up to 1000x digital magnification

Dimensions
Approx. 300mm x 200mm x 450mm Millimeter (mm)

Focus Range
Manual/Auto adjustable Millimeter (mm)

Eyepieces
WF10x (Wide Field)

Eyepiece Tube
Inclined, rotatable

Illumination
Built-in LED ring light, adjustable brightness

Coarse Adjustment Range
20mm

Fine Adjustment Range
2mm

Working Stage
Mechanical stage with X-Y movement Square Millimeter (mm2)

Still Image Capture Resolution
Up to 4032 x 3024 pixels

Video Capture Resolution
1920 x 1080 (Full HD)

Image Format
JPG, BMP, AVI

Interpupillary Distance
55mm - 75mm adjustable Millimeter (mm)

Objective Achromatic
4x, 10x, 40x, 100x (oil)

Condenser
NA 1.25 Abbe condenser with iris diaphragm

Light Source
Adjustable LED illumination (Top/Bottom)

Storage Temperature
-20C - 60C

Camera Mount
C-mount adapter compatible

Weight
Approx. 6.5 kg

Display Options
PC monitor/HDMI display support

Image Sensor Size
1/2.7 inch

Operating Temperature
0C - 40C

Power Supply
AC 110/220V, 50/60Hz

Operating System Compatibility
Windows 7/8/10, Mac OS

Color Reproduction
True color, high fidelity

Software Features
Measurement, annotation, calibration, image enhancement

Digital Inspection MicroscopeCamera JBM-PL6 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash in Advance (CID), Cheque

Delivery Time
3 Days

Sample Policy
Within a certain price range free samples are available

Main Export Market(s)
Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Asia, Africa

About Digital Inspection MicroscopeCamera JBM-PL6

Sensor resolution	8 MP
Resolution	HD
Magnification	50x
Output interface	USB 2.0
Sensor size	1/2.8 inch
Frame rate	60 fps
Mount type	Built in
Model Name/Number	JBM-MZ50
Camera type	C mount camera, CMOS camera, USB camera, HDMI camera
PC software	Windows Mac, Windows
Power supply	12 V DC
Zoom Objective	0.7X-5X
Eyepiece	0.4X
Zoom Ratio	1:7
Base vertical post height	240mm
Focus travel	50mm
Base Size	320x260x16mm

Minimum order quantity: 10 Piece

Specification:

2K HDMI video output
High-performance and fast-response video
2K/1920P switch adaptively, Preview frame rate 30fps, max recording frame rate: 30fps
SONY Sensor, sensor size:1/2.8
Pixel(m) : 1.451.45
Resolution: 2K Ultra HD (8mp 19201080)
Preview frame rate 2K@30fps / 1080P@30fps
Support U disk storage
Method of Operation : Mouse
Power DC : DC12V
Video Output method : HDMI
White Balance : Auto / Manual / One-push control
Exposure : Auto / Manual
Scanning method: Line by line scanning
Operating Temperature: 050
Magnification / Zoom: Support
Menu language: English

Advanced Imaging and Compatibility

The JBM-PL6 digital microscope camera comes equipped with a powerful 12MP CMOS/CCD sensor, providing clear, true-color images. With compatibility for Windows 7/8/10 and Mac OS, and both USB 2.0 and HDMI outputs, it ensures seamless connection to both PC monitors and HDMI displays, making setup easy and flexible for various working environments.

Precision Optics and User-Friendly Features

This microscope boasts a trinocular head, adjustable focal distance from 10mm to 500mm, and four achromatic objective lenses (4x, 10x, 40x, 100x oil). The mechanical X-Y stage, manual/auto focus adjustment, and adjustable LED illumination support meticulous sample handling. Measurement, annotation, and calibration tools enhance user productivity and data accuracy.

Durable Design and Practical Operation

Weighing approximately 6.5 kg with a solid build, the JBM-PL6 is ideal for laboratories, manufacturing, and educational settings. Operating between 0C and 40C, and easily storable at -20C to 60C, it adapts to diverse environments. The supplied accessories, including a dust cover, calibration slides, and a power adapter, ensure a smooth user experience.
