Horizontal digital inspection Microscope JBM-HZ45i

Horizontal digital inspection Microscope JBM-HZ45i Specification

Features
HDMI live view, on-screen measurement, snapshot, image/video recording, anti-flicker technology.

Spare Parts
LED ring, power adaptor, USB cable, calibration slide.

View Head
Horizontal viewing, ergonomic digital display.

Focus System
Coarse and fine manual control.

Theory
Horizontal digital inspection system designed for high-precision imaging and inspection tasks.

Drawtube
Digital drawtube with integrated sensor housing.

Sensor
High-definition CMOS sensor.

Resolution
1920 x 1080 pixels (Full HD).

Interface
USB 2.0/3.0, HDMI output.

Frame Rate
Up to 60 fps (via HDMI/USB 3.0).

Focal Distance
100 mm - 320 mm (adjustable).

Magnification
0.7x - 4.5x (zoom lens system).

Dimensions
410 mm (L) x 210 mm (W) x 430 mm (H).

Focus Range
Manual fine focusing, 50 mm travel.

Eyepieces
Not applicable (digital output without optical eyepiece).

Eyepiece Tube
Not present (digital system).

Illumination
Adjustable LED ring light (brightness control).

Coarse Adjustment Range
20 mm.

Fine Adjustment Range
0.002 mm precise tuning.

Working Stage
Large flat X-Y stage, anti-vibration.

Still Image Capture Resolution
1920 x 1080 pixels.

Video Capture Resolution
1080p at 60 fps.

Image Format
JPEG/PNG/BMP for still images.

Interpupillary Distance
Not applicable.

Objective Achromatic
Plan achromatic zoom objectives.

Condenser
Not required (for digital imaging).

Light Source
Integrated high-intensity LED.

White Balance
Automatic and manual modes available.

Weight
Approx. 4.5 kg.

Color
Industrial grey/black finish.

Auto Exposure
Supported for optimum image clarity.

Environmental Safety
Anti-static housing, RoHS compliant.

Operating System Support
Windows 7/8/10, Linux, Mac OS.

Working Temperature
5C to 40C.

Camera Mount
C-mount for easy sensor replacement.

Application Areas
Electronics QC, PCB inspection, material science, education, laboratory.

Software
Included analysis software with measurement tools, annotation, calibration.

Power Supply
12V DC external adaptor.

Digital Zoom
Up to 6x digital zoom in software interface.

Horizontal digital inspection Microscope JBM-HZ45i Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
3 Days

About Horizontal digital inspection Microscope JBM-HZ45i

Microscope type	Video
Magnification	45x
Magnification range	7x to 45x
Illumination	LED ring
Working distance	110 mm
Observation head	Video only
Mounting type	Bench stand
Model Name/Number	JBM-HZ45i
Light Source	LED
Camera	HDMI camera, C mount camera, USB camera
Field of view	25 mm
Base size	380mm X 250mm
Frame diameter	50mm
Load table size	180mm X 120mm
Weight:	3.9kg

Minimum order quantity: 1 Piece

Monozoom Microscope JBM-HZ45i

PRODUCT DESCRIPTION

Zoom magnification power offering sharp images

Metal framework with solid base plate

0.7X-5.0X zoom objective

C-mount lens

Long working distance

Sharp images over a super wide field view

Advanced Imaging Performance

Featuring a high-definition 1920 x 1080 pixel CMOS sensor and a zoom lens system (0.7x-4.5x), the JBM-HZ45i delivers crisp, dynamic imaging. The microscope's auto exposure and white balance (manual/automatic) functions ensure precise color reproduction and optimal clarity, even under varying lighting conditions. Live video streaming up to 60 fps and still image capture make it suitable for high-throughput inspection work.

Integrated Measurement & Analysis Tools

The included software suite empowers users with on-screen measurement, annotation, and calibration capabilities. Users can easily record, analyze, and archive findings with support for multiple image formats (JPEG, PNG, BMP) and video recording at 1080p. Beneficial for quality control and documentation, the analysis tools help streamline workflow in electronic, material science, and laboratory settings.

Ergonomic & Durable Design

Crafted with industrial-grade anti-static materials, the JBM-HZ45i is both robust and ergonomic. The large, flat X-Y stage with anti-vibration design aids in sample stability during inspection. Its horizontal viewing head and digital display eliminate the need for optical eyepieces, reducing operator fatigue and enhancing comfort during extended use.

FAQ's of Horizontal digital inspection Microscope JBM-HZ45i:

Q: How do I set up the JBM-HZ45i Microscope for initial use?

A: Begin by placing the microscope on a stable, vibration-free surface. Connect the power using the 12V DC adaptor. Attach the camera via the C-mount and connect your preferred display or computer using HDMI or USB 2.0/3.0. Install the included software on a compatible Windows, Mac, or Linux system and follow the calibration prompts to start imaging.

Q: What benefits does the digital zoom and measurement software provide?

A: The integrated software allows users to zoom digitally up to 6x on captured or live images, measure distances and angles on-screen, annotate findings, and calibrate the system. This streamlines the inspection process, speeds up quality control tasks, and ensures highly accurate documentation and analysis.

Q: When should I use the auto exposure and white balance features?

A: Auto exposure and automatic white balance are ideal for dynamic or mixed-light environments, providing consistent image clarity and color accuracy without manual adjustment. Manual white balance can be used when a specific color calibration is required for specialized analysis.

Q: Where are the JBM-HZ45i applications most effective?

A: This microscope is best utilized in electronics quality control, printed circuit board (PCB) inspection, material science studies, laboratory testing, and educational demonstrations, particularly in industries and settings that demand high-magnification digital imaging and reliable measurement capabilities.

Q: What is the process for replacing the sensor on the JBM-HZ45i?

A: Thanks to the C-mount design, sensor replacement is straightforward. Power off the microscope, remove the current sensor from the C-mount, and attach the new compatible sensor. Secure it properly before powering up and recalibrating through the software interface.

Q: How does the anti-static, RoHS-compliant housing benefit usage?

A: The anti-static housing protects sensitive samples-such as electronic components-from electrostatic discharge, reducing the risk of damage. RoHS compliance ensures that the device is manufactured without hazardous substances, promoting user safety and environmental responsibility.

Q: Which accessories and spare parts are included with the microscope?

A: The JBM-HZ45i package generally includes a spare LED ring, power adaptor, USB cable, and calibration slide. These spares ensure minimal downtime and sustained precision in imaging and analysis operations.
