PCB Inspection Digital Microscope JBM-DM2

Send Inquiry

Request To Call Back

PCB Inspection Digital Microscope JBM-DM2

Name: PCB Inspection Digital Microscope JBM-DM2
Brand: JB INSTRUMENTS PVT LTD
Price: 77000.0 INR
Availability: InStock

Price 77000.0 INR/ Set

Get a Price/Quote

MOQ : 1 Set

PCB Inspection Digital Microscope JBM-DM2 Specification

Focus System
Manual by ring adjustment

Features
Snapshot and video recording; Calibration software included; Portable lightweight design; Suitable for PCB, electronics, and small parts inspection

View Head
Digital, upright

Spare Parts
LED ring, USB cable (optional on request)

Theory
Digital USB Inspection Microscope for electronics and PCB analysis

Drawtube
Monocular

Sensor
CMOS digital sensor

Resolution
5 Megapixels (2592 x 1944)

Interface
USB 2.0

Frame Rate
Up to 30 fps

Focal Distance
10 mm to 150 mm (Adjustable)

Magnification
10x to 300x (Digital)

Dimensions
185 mm x 140 mm x 35 mm (Microscope body only)

Focus Range
Manual focus, 0 mm to 150 mm

Eyepieces
Not applicable (digital view only)

Illumination
8-LED ring, adjustable brightness

Coarse Adjustment Range
Up to 40 mm

Fine Adjustment Range
Not available (digital focus only)

Working Stage
Metallic base stage with anti-slip mat

Still Image Capture Resolution
5 MP (2592 x 1944 pixels)

Video Capture Resolution
HD 720p, up to 1280 x 720 pixels

Image Format
JPEG, BMP

Light Source
Built-in high-intensity LED ring

Software Support
Image and video capturing, measurement, and editing

Packaging
Box with shock-absorbing foam, accessories included

Operation Mode
Plug-and-play; no driver required for basic use

Zoom Type
Digital zoom

Mounting Stand
Metal stand with height adjustment

Power Supply
USB powered (no external adapter required)

Operating System Compatibility
Windows XP/Vista/Win7/8/10, Mac OS

Color
Black/Silver finish

Weight
Approx. 350 grams

Camera Angle
Adjustable vertical and tilt view

PCB Inspection Digital Microscope JBM-DM2 Trade Information

Minimum Order Quantity
1 Set

Delivery Time
3 Days

About PCB Inspection Digital Microscope JBM-DM2

Microscope type	Digital
Magnification	45x
Magnification range	7x to 45x
Illumination	LED ring
Light Source	LED
Working distance	110 mm
Observation head	Video only
Mounting type	Bench stand
Model Name/Number	JBM-DM2
Usage/Application	circuit board inspection and soldering
Camera	HDMI camera, Built in camera
Field of view	25 mm
Warranty	1 Year
Optical zoom	0.7X-4.5X
HD camera	1/3" COMS 4MP
Large objective	1X, 1.4x, 0.5x
Base	225mm
Digital Microscope	77000

Minimum order quantity: 1 Piece

JBM-DM2 all-in-one has a solid and excellent exterior design. It accumulation unremitting zoom optical lens and HD digital camera. The display, Camera and ring light are all powered by one power supply to avoid the mess of mixed wires 4 megapixels high-definition CMOS image sensor, excellent image quality, can truly restore the cooler, sharpness and contrast of the image, The frame rate of HD reached to 30 fps, instantaneously satisfied the demand for speed and transparency.

MODEL	JBM-DM2
Display	IPS10 inch HD screen tilting angle (-5 to 15)with Geometrical Measurements function
Optical zoom	Continuous zoom objective 0.7X-5X
HD camera	1/3 COMS 4MPBuilt-in camera module, real-time HDR, built-in OSD menu,
Large objective	1X large objective lens, WD105mm
1.4X large objective lens, WD100mm
0.5X large objective lens, WD170mm
Light source	LED ring light: 56 LEDs with dimming knob, switch, color temperature 5000-5500K
Data Storage	Built-in storage 16GB, support SD card storage,
Output interface	HDMI, USB 2.0,Mini usb2.0, support wireless mouse and keyboard
Base	Flat large base with Vertical track type, stroke 225mm
Standard Accessories	USB cable 1.5m; HDMI cable 5m, FTH 26W LED ring lamp & 12V,3. 3A adaptor

PCB Microscopes are essential tool in electronic manufacturing, repair and debugging process engaged in difficult tasks such as circuit board inspection and soldering. It provides magnification and illumination to help users inspect and work on small components and solder joints on PCB with accuracy and with higher illumination options they facilitate a well-lit workspace for precise work.

If you are in the business of electronic manufacturing or suppliers, JB Microscope provide you a wide range of PCB Inspection Microscope specially designed for PCB that help you accomplish effective and accurate. These microscopes are essential for efficient and precise PCB Inspection whether it be for quality control, rework failure analysis or research and development purposes.

The Performance of PCBs regardless of whether they are single-sided, double-sided or multilayer is heavily reliant on the quality of soldering through hole and components such as diodes, IC, Chips and capacitors. It is crucial to thoroughly check these components to ensure they meet the necessary standards.

PCB inspection with JBM microscopes can be performed fast and easily. View a large overview of the sample and simply zoom in on a region of interest with high concert zoom optics, view high quality images, long working distance, 3D image viewing, solder joints and more.

There are two types of microscope for PCB Inspection

Digital Microscopes
Stereo Microscopes

The main difference lies in the way the viewer can view their work. Either using eyepiece or viewing the image on a screen.

Digital Microscopes project the image on the screen which can be more ergonomic allowing for less operator fatigue. Whereas Stereo microscopes are designed to view through eyepiece and provide a 3D view.

Comprehensive PCB and Electronics Inspection

With magnification up to 300x and a 5MP CMOS digital sensor, the JBM-DM2 delivers precise visual analysis for electronics, PCBs, and small components. The adjustable LED ring illuminates your subject, minimizing shadows and enhancing detail, making it suitable for technicians and engineers alike.

Easy Integration and Hassle-Free Operation

Designed with a plug-and-play interface, this microscope requires no external adapters or special drivers for basic use. Compatible with multiple Windows and Mac OS versions, the included software allows for seamless image and video capture, measurement, editing, and calibration on most computers.

Built for Durability and Portability

Featuring a robust metal mounting stand and compact, lightweight construction, the JBM-DM2 is engineered for convenient use at workbenches, labs, and field sites. The anti-slip mat and shock-absorbing packaging ensure safety in transport and continuous reliable performance.

FAQ's of PCB Inspection Digital Microscope JBM-DM2:

Q: How do I set up the JBM-DM2 microscope for use with my computer?

A: You can set up the JBM-DM2 by simply connecting it to your computer via the included USB cable. For basic operation, no driver installation is required. For advanced features such as measurement and image editing, you may install the supplied software, which is compatible with Windows XP/Vista/7/8/10 and Mac OS.

Q: What are the key benefits of using this digital microscope for PCB inspection?

A: The primary benefits include high-resolution imaging, adjustable digital magnification up to 300x, built-in LED illumination for enhanced visibility, and software for image capture, video recording, measurement, and calibration. Its portable, lightweight design makes it efficient for both laboratory and on-site inspection.

Q: When should I use the calibration software provided with the microscope?

A: You should use the calibration software before conducting precise measurements or comparative analysis. Calibration ensures measurement accuracy when inspecting PCBs, electronic circuits, or small mechanical components, particularly if you change magnification settings.

Q: Where can the JBM-DM2 be effectively utilized?

A: The microscope is ideal for workbenches, research labs, manufacturing facilities, as well as dealer and retail environments. Its durable design and portable packaging allow for reliable use in offices, field sites, service centers, or educational settings.

Q: What process should I follow to capture and store images or videos using the microscope?

A: Connect the microscope to your computer and launch the included software. You can then capture images in JPEG or BMP formats and record videos in HD 720p (up to 1280x720 pixels) by using the snapshot and video record functions. Files can be saved directly to your computer for documentation or further analysis.

Q: How does the height and camera angle adjustment work on this microscope?

A: The JBM-DM2 is mounted on a sturdy metal stand equipped with a height adjustment mechanism, allowing you to change the elevation smoothly. The camera can be tilted or moved vertically, making it easier to inspect objects from various angles and focal distances between 10 mm and 150 mm.

Tell us about your requirement
